PLC6462
Product Model: PLC6462
Overview：
PLC6462 uses the mainstream ARM kernel 32 bit microprocessor, Modbus RTU and BACnet MS/TP supports two protocols (choose one), can realize the rapid expansion of I/O module controller.
Protocol specification：
RS485-1 port: the PLC download port. It supports Modbus RTU server and is easily integrated by the host computer. Multiple software simultaneous access is not supported.
RS485-2 port: supporting Modbus RTU protocol and BACnetMSTP slave service, can quickly realize data acquisition and communication with the slave station equipment supporting Modbus RTU protocol.
Please refer to the PLC user Manual for specific operation.
Main Parameter：
| Processor |
32 bit |
| Clock Frequency |
72MHZ |
| Memory |
64KB flash, 20KB random access memory |
| Power |
DC/AC 24V |
| Communication |
Modbus RTU(2.4k/4.8k/9.6k/19.2k)
BACnet MS/TP(9.6k/19.2k/38.4k/76.8k) |
| Digital Input |
Support 24VDC <3A |
| Digital Output |
Support dry contact output |
| Analog Input |
12 bit resolution, support 0-10V, 0-20mA input |
| Analog Output |
10 bit resolution, support 0-10V, 0-20mA output |
Model specification：
|
Product Model |
BI/DI |
BO/DO |
AI |
AO |
|
PLC |
6 |
4 |
6 |
2 |
Product display ：
Correspondence diagram of controller wiring diagram
|
Register Type |
Segment Type |
Register |
Register Address |
Function Code |
|
Y
|
Bit element |
Y0-Y377 |
0001-0256 |
1,5,15 |
PLC component and MODBUS protocol address
X |
Bit element |
X0-X377 |
1201-1456 |
1,5,15,2 |
|
M |
Bit element |
M0-M2477 |
2001-4048 |
1,5,15 |
|
SM |
Bit element |
SM0-SM511 |
4401-4912 |
1,5,15 |
|
M |
Bit element |
M0-M2047 |
2001-4048 |
1,5,15 |
|
T |
Bit element |
T0-T255 |
8001-8256 |
1,5,15 |
|
C |
Bit element |
C0-C255 |
9201-9456 |
1,5,15 |
|
D |
Word element |
D0-D4095 |
0001-4096 |
3,6,16 |
|
SD |
Word element |
SD0-SD511 |
8001-8512 |
3,6,16 |
|
T |
Word element |
T0-T255 |
9001-9256 |
3,6,16 |
|
C |
Word element |
C0-C199 |
9501-9700 |
3,6,16 |
|
C |
Word element |
C200-C255 |
9701-9256 |
3,16 |
